CRBC 02008CRBC 02508CRBC 03010CRBC 03510CRBC 04010CRBC 04510CRBC 05013CRBC 06013CRBC 07013CRBC 08013
| 型號 | 尺寸 (mm) | 油孔 dOH (mm) |
基本額定載荷 (kN)? | ?靠肩尺寸 (mm) | |||||
| 內(nèi)徑 (d) |
外徑r (D) | 寬度 (B, T) |
動載荷 C | 靜載荷 C0 | da | Da | ra (max) |
||
| CRBC 02008 | 20 | 36 | 8 | 1.5 | 4.1 | 4 | 22.9 | 30.8 | 0.6 |
| CRBC 02508 | 25 | 41 | 8 | 1.5 | 4.5 | 4.8 | 27.9 | 35.8 | 0.6 |
| CRBC 03010 | 30 | 55 | 10 | 1.5 | 8.2 | 9.2 | 35 | 46.8 | 0.6 |
| CRBC 03510 | 35 | 60 | 10 | 1.5 | 8.5 | 10 | 40 | 51.8 | 0.6 |
| CRBC 04010 | 40 | 65 | 10 | 1.5 | 9.3 | 11.6 | 45 | 56.8 | 0.6 |
| CRBC 04510 | 45 | 70 | 10 | 1.5 | 9.6 | 12.5 | 50 | 61.8 | 0.6 |
| CRBC 05013 | 50 | 80 | 13 | 2 | 18.9 | 23.4 | 57.2 | 72 | 0.6 |
| CRBC 06013 | 60 | 90 | 13 | 2 | 20.3 | 27 | 67 | 82 | 0.6 |
| CRBC 07013 | 70 | 100 | 13 | 2 | 21.7 | 30.6 | 77 | 92 | 0.6 |
| CRBC 08013 | 80 | 110 | 13 | 2 | 22.8 | 34.2 | 87 | 102 | 0.6 |
| CRBC 08016 | 80 | 120 | 16 | 2.5 | 30.2 | 44.8 | 92 | 109 | 0.6 |
| CRBC 09016 | 90 | 130 | 16 | 2.5 | 30.8 | 47.4 | 104 | 120 | 1 |
| CRBC 09020 | 90 | 140 | 20 | 2.5 | 39.7 | 60.2 | 104 | 120 | 1 |
| CRBC 10016 | 100 | 140 | 16 | 2.5 | 32.5 | 52.3 | 112 | 129 | 1 |
| CRBC 10020 | 100 | 150 | 20 | 2.5 | 40.4 | 63.6 | 117 | 132 | 1 |
| CRBC 11020 | 110 | 160 | 20 | 2.5 | 42.7 | 70.2 | 126 | 143 | 1 |
| CRBC 12016 | 120 | 150 | 16 | 2.5 | 28.1 | 50.3 | 126 | 143 | 1 |
| CRBC 12020 | 120 | 170 | 20 | 2.5 | 44.9 | 76.9 | 136 | 153 | 1.5 |
| CRBC 12025 | 120 | 180 | 25 | 2.5 | 66.3 | 109 | 138 | 158 | 1.5 |
| CRBC 13025 | 130 | 190 | 25 | 2.5 | 67.8 | 114.8 | 148 | 168 | 1.5 |
| CRBC 14025 | 140 | 200 | 25 | 2.5 | 69.5 | 120.6 | 161 | 178 | 1.5 |
| CRBC 15025 | 150 | 210 | 25 | 2.5 | 73.1 | 131.9 | 168 | 188 | 1.5 |
| CRBC 40035 | 400 | 480 | 35 | 3 | 219.4 | 523.9 | 426 | 447 | 2.5 |
